Jaw crusher
The jaw crusher is a motor-driven belt and pulley, and the movable jaw moves up and down through an eccentric shaft. When the movable jaw rises, the angle between the toggle plate and the movable jaw becomes larger, which pushes the movable jaw plate to approach the fixed jaw plate, and the material is crushed multiple times by squeezing, rubbing, and grinding between the two jaw plates. When the movable jaw descends, the angle between the toggle plate and the movable jaw becomes smaller. The movable jaw plate leaves the fixed jaw plate under the action of the pull rod and the spring, and the crushed material passes through the discharge port in the lower jaw cavity freely under the action of gravity.
Information for an application discussion
Connect product documents to the actual installation position using the information below. This intake guide does not establish that a designation is suitable for the equipment.
- Equipment
- Equipment name, manufacturer, model, purpose, bearing position, full designation and suffixes; mark the bearing position and revision on drawings.
- Operation
- Load directions and available values, speed range, starts and operating cycle, lubrication, temperature records and environment; retain units and measurement conditions.
- Observations
- State whether the request concerns a new selection, maintenance replacement or operating problem; add timing, maintenance history, photographs and inspection records.
